Best Graphics Card For AutoCAD 2022

Are you looking for the best Graphics card for AutoCAD or 3D designing? You will accept that your workstation is the most important thing, whether you produce visual effects, 3D or 2D Models, or work in the film and industrial design industries.

When you dive into 3D modeling and visualization, a powerful graphics card becomes your most important need. Slow rendering or processing will also slow you down. In particular, you want the best 3D rendering and modeling graphics card to get the best out of your applications and improve efficiency while working on complicated projects that require high processing power.

Rendering takes time, but once you have a high-performance graphics card, your rendering time can be reduced to half or even more. I have chosen the best graphics cards for AutoCAD.

Best Graphics card for AutoCAD 2019 & 2020

Product TitleDesignModelCheck Price
Best GPU for AutoCADAsus TUF GeForce RTX 3090 OC 24 GB Graphics cardASUS TUF GeForce RTX 3090 24 GBView at Amazon
Best Midrange GPU for AutoCADBest graphics card for autocadMSI GeForce RTX 3070 Gaming X TrioView at Amazon
Superb performance for its priceAMD Radeon Pro WX 3100View at Amazon
Expensive but Outstanding performanceAMD Radeon Pro WX 7100View at Amazon
Optimized for design softwaresPNY Nvidia Quadro RTX 4000View at Amazon

1. Asus TUF GeForce RTX 3090 OC 24 GB – Best Graphics card for AutoCAD

Asus TUF GeForce RTX 3090 OC 24 GB Graphics card

Cuda Cores: 10,496 | Boost Clock: 1,695 MHz | Memory: 24 GB GDDR6X | Memory speed: 19.5 Gbps | Memory bandwidth: 936.2 GB/s | Outputs: 1x DisplayPort and 3x DisplayPort| TDP: 220 Watt | Suggested PSU: 650 Watt


+ Excellent Performance
+ Superb Built Quality
+ Satisfying Features
+ 24 GB of GDDR6X memory
+ Dual Bios
+ Amazing Thermal Performance


– Expensive

– Slower and more expensive than RTX 4070 Ti

View at Amazon

An overclocked GPU with a powerhouse performance, the Asus TUF RTX 3080 is one of the best GPUs on the market today. The GPU is packed with 24 GB GDDR6X memory with a 936.2 GB/s Memory Bandwidth, which is more than 5x than recommended.

The Asus TUF RTX 3090 outperformed AutoCAD 3D and 2D designing. It can handle every rendering task that you can throw at it. In AutoCAD, its performance was 25% better than Nvidia RTX 2080 Ti. Not only it performs exceptionally in AutoCAD, but its performance was also very satisfying 3Ds MAX, Maya, and Solidworks. The RTX 3090 performed much better than both AMD RX 6900 XT and RTX 3080 Ti.

Furthermore, this GPU offers great features that will enhance your work experience. You can easily pair multiple monitors with 2x HDMI 2.1 and 3x DisplayPort 1.4a outputs, and a single HDMI 2.1 is capable of supporting 4K 120 Hz or 8K 60 Hz displays. The Triple fan also performs very well in keeping the card cool. For such a powerful GPU, the GPU still remained below 67C, despite several hours of continuous AutoCAD use.

Overall, the ASUS TUF GeForce RTX 3080 OC is the Best Graphics card for AutoCAD 2022. It can easily render advanced photorealistic 3D rendering in much lesser time. The GPU looks good, has an excellent cooling system, and can easily support multiple 4K monitors with ease. Despite its good performance, the GPU is twice as expensive as the Nvidia RTX 3070.

2. MSI GeForce RTX 3070 Gaming X Trio – Best Mid Range Graphics card for AutoCAD

MSI RTX 3070 gaming X Trio

Cuda Cores: 5,888 | Boost Clock: 1,830 MHz| Memory: 8 GB GDDR6 | Memory speed: 14 Gbps | Outputs: 1x DisplayPort and 3x DisplayPort| TDP: 220 Watt | Suggested PSU: 650 Watt


+ Amazing Price/performance ratio
+ Faster and cheaper than RTX 2080 Ti
+ Extremely quiet
+ Very low temperature while working
+ PCI Express 4.0
+ Support for HDMI 2.1, AV1 decode


– Large price increase over Founders Edition

View at Amazon

The MSI RTX 3070 Gaming X Trio is a very high-performance card for AutoCAD. The MSI GeForce RTX 3070 Gaming X Trio brings real-time power ray tracing and AI. It comes with almost twice the better price/performance ratio compared to RTX 2080 Ti and 3-4% better performance. In terms of price, The performance of MSI RTX 3070 is also better than the Nvidia RTX 4000 and Nvidia Quadro P6000 (24 GB). These performances definitely make the RTX 3070 the Best Mid-range Graphics card for AutoCAD.

MSI provided excellent coolers with its RTX 3070 Gaming X Trio. The Graphics card remained very cool and produced noise that was hardly audible. The Idle fan stop feature is also included, which turns off the fans, and lowers the power consumption during light usage. The GPU is also very power efficient, so you don’t have to worry about High power Usage.

This GPU is not for a mid-range workstation, and it’s for a big workstation. Not only that, but it’s also the best GPU under 600$. The MSI Gaming X Trio is currently one of the best GeForce RTX 3070 graphics cards available.

3. AMD Radeon Pro WX 3100 – A Great Budget Professional Graphics card for AutoCAD

Image: AMD

Cuda Cores: 512 | Boost Clock: 1219 MHz | Memory: 4 GB GDDR5 | Memory speed: 6 Gbps | Outputs: 1x DisplayPort and 2x mini-DisplayPort | TDP: 65 Watt | Suggested PSU: 350 Watt


+ Superb performance for its price
+ It doesn’t require a power connector


–  In specific workloads, Nvidia takes the advantages

View at Amazon

If you are on a budget side but still need a good and professional Graphics card then this Radeon Pro WX 3100 GPU might be the best option for you. The Radeon Pro WX 3100 was released in June 2017 and is an AMD performance professional graphics card. The performance of this GPU is very close to Nvidia Quadro M400 and is a little bit behind then the AMD WX 4100. It is a low-end or entry-level graphics card for work, So we can’t expect high performance from it. In AutoCAD, Its performance is 34% worse than AMD RX 580 8GB.

The GPU has Zero Core power technology that shuts the GPU down for low power consumption during light GPU usage. This Graphics card has 512 shader units, and AMD paired 4GB GDDR5 memory with it. It is a single-slot graphics card, and you don’t need any additional power connector to connect the GPU. As a result, the GPU consumes very little power (60-65W), and you don’t need to purchase a powerful and expensive power supply.

4. AMD Radeon Pro WX 7100 – Expensive but Outstanding performance

Image: AMD

Cuda Cores: 2,304 | Boost Clock: 1243 MHz | Memory: 8 GB GDDR5 | Memory speed: 7 Gbps | Outputs: 4x DisplayPort | TDP: 130 Watt | Suggested PSU: 350 Watt


+ Powerful Graphics card
+ It has outstanding performance and enhanced interactivity for designers and engineers
+ Suitable for AutoCAD(2D) and for SolidWorks(3D)


– Expensive

View at Amazon

The Radeon Pro WX 7100 is designed by AMD for production work like 3D designing, Video editing, and VR content. Like the AMD WX 3100, it is also a professional graphics card which means it is good only for production work, not for gaming. The performance of the Radeon Pro WX 7100 is very close to AMD RX 580 8GB and is almost 33% better than AMD WX 3100, 9-10% better than WX 5100 8GB. Compared to its release price of 799$, the RX 580 8GB is a better option.

It also has Zero Core power technology, just like the WX 3100. This GPU is a single slot, and you need a 1x 6-pin power connector from which GPU draws power. The GPU consumes a total power of 130 Watt. The Graphics card has 2304 shading units and 32 ROPs. AMD has paired an 8GB GDDR5 memory. The Radeon Pro WX 7100 is also a good option if you can find one at a low price.

5. PNY Nvidia Quadro RTX 4000 – Best Professional GPU that is Optimized for design softwares

Image: Nvidia

Boost Clock: 1545 MHz| Memory: 8 GB GDDR6 | Memory speed: 13 Gbps | Outputs: 3x DisplayPort and 1x USB Type-C| TDP: 160 Watt | Suggested PSU: 450 Watt


+ Lower power consumption
+ Supports Ray tracing
+ It is optimized for design tools


– High Price

View at Amazon

The PNY Nvidia Quadro RTX 4000 was released in 2018 as a high-end professional graphics card with a price tag of 899$. Its overall performance is very close to Nvidia RTX 2060 Super and much better than RTX 2060 6GB. The GPU can easily render high-particle designs. The Graphics card has 2304 Cuda cores, and 36 raytracing accelerated cores. The GPU is paired with 8GB GDDR6 Memory. This GPU is designed for Advanced rendering. As compared to Nvidia Quadro P5000 (16 GB), which was a very expensive GPU; The Nvidia RTX 4000 is 25% better in performance in 3D rendering. Not only in Designing, but it is also an excellent GPU for Deep Learning.

The PNY RTX 4000 is a single slot card that draws power from a 1x 8-pin power connector. The card consumes almost 150-160 Watts during 3D rendering. Only the GPU’s price makes it a barrier for many 3D designers.

Conclusion – Best Graphics Card for AutoCAD 2022

The Best Graphics Card for AutoCAD is ASUS TUF GeForce RTX 3090 OC. It reaches the top of the list of fastest graphics cards in terms of gaming and productivity.

Nvidia’s RTX 3070 GPU is the best midrange option, it may not be the fastest in the RTX series, but it offers the best performance for the price.

The PNY Nvidia Quadro RTX 4000 is the second-best fastest graphics card. The reason why it’s placed in the second position is its price. The GPU cost so much, and it’s also not preferred by many designers for that reason. But, it’s preferred over other GPUs on the list because it is a very optimized GPU for Productive tasks, especially when it comes to AutoCAD 2D or 3D designing.


The following answers might be of interest to you:

Is PNY Nvidia Quadro RTX 4000 a good option for Beginners?

No, the PNY Nvidia Quadro RTX 4000 is not a good option if you are just starting your AutoCAD career because the GPU is designed for Professionals who want to render heavy design and time taking designs. It’s also an expensive professional GPU.

Is Nvidia RTX 3090 Ti a better option than RTX 3070?

Yes, the Nvidia RTX 3090 Ti is a better and more powerful option for AutoCAD. But, the RTX 3090 Ti doesn’t provide a Good price/performance ratio than RTX 3070.

What is the recommended GPU requirement for AutoCAD 3D or 2D designing?

For good rendering, you need at least a 4 GB Graphics card with a minimum of 106 GB/s Memory Bandwidth.

Are Quadro and Radeon Pro Graphics cards good for Gaming?

No, Quadro and Radeon Pro graphics cards are not a good options for gaming. If you want to do gaming + 3D rendering, we recommend GeForce Graphics cards.
